Specification
| Model No： | OUGE-RXTY-18A | Lighting Fixture Size： | 19x13x5040 (mm) |
| Specification： | 5m/roll | Outer shell Material： | Transparent Modified PVC |
| LED Color： | W+W/RGB/R/G/B/W | Control Method： | ON/OFF、SPI |
| Protect Grade： | IP68 | Voltage： | DC12V/DC24V |
| salt spray test： | Anti-salt spray | Power： | 5W/7W/7.5W/9W/10W/12W /14W |
| Outer Shell Fireproof Grade： | V-0 | Environment： | Outdoor |
| Electrical Safety Class： | Category III | Environment Temperature： | -20℃~+55℃ |
Product Specifications And Parameters：
| No. | Control Method： | LED color： | Voltage： | Power： | Standard Configuration： | Standard Configuration： |
| 01 | ON/OFF | R/G/B/W… | DC24V | 5W/m | 60pcs per meter | / |
| 02 | ON/OFF | R/G/B/W… | DC24V | 10W/m | 120pcs per meter | / |
| 03 | SPI | R/G/B/W | DC24V | 5W/m | 60pcs per meter | 5 pixels/meter |
| 03 | SPI | R/G/B/W | DC24V | 5W/m | 60pcs per meter | 10 pixels/meter |
| 04 | SPI | R/G/B/W | DC24V | 7.5W/m | 96pcs per meter | 8 pixels/meter |
| 05 | SPI | W+W | DC24V | 5W/m | 60pcs per meter | 5 pixels/meter |
| 06 | SPI | W+W | DC24V | 7.5W/m | 96pcs per meter | 8 pixels/meter |
| 07 | SPI | RGB | DC12V | 7W/m | 30pcs per meter | 10 pixels/meter |
| 08 | SPI | RGB | DC24V | 14W/m | 60pcs per meter | 10 pixels/meter |
| 09 | SPI | RGB | DC24V | 9W/m | 36pcs per meter | 6 pixels/meter |
| 10 | SPI | RGB | DC24V | 12W/m | 48pcs per meter | 8 pixels/meter |
